Conventional shelving spends most of its floor area on aisles nobody is standing in. A mobile compactor puts the bays on rails so they close against each other, leaving a single aisle that opens wherever you need it. In a records room that recovers a large share of the floor, which is why hospitals, banks, courts, colleges and government offices across Delhi NCR use them.
How they are built
Sizes and capacity
Units are 2000 mm or 2200 mm high with 4 to 6 levels per bay, carrying 300 kg to 1000 kg per bay, in systems from 5 m to 12 m long. Bays can be single-access or double-access.
Either embedded flush in the floor, which is neater and lets a trolley roll across, or surface-mounted on a sub-frame to avoid cutting the slab. In leased or already-finished buildings, surface mounting is usually what decides it.
Safety and security
We fit anti-tilt guides and a brake so a bay cannot run while someone is in the aisle, plus central locking where contents are confidential. Shelf dividers, file separators and index card holders are available for records duty. For pure document storage see file storage compactors and file compactors; for static archive shelving see record storage racks.
Beyond files
The same mechanism suits spares, tooling, textiles and pharmacy stock. Where goods are palletised rather than hand-loaded, pallet racking is normally the better answer. Where the constraint is height rather than aisle width, look at a mezzanine floor instead.
Ask for a bay layout
Send the room dimensions, the ceiling height, the running metres of files you hold today, and whether the slab can be cut for rails. We will come back with a bay layout and a quotation. Call +91-9811015963. We manufacture, supply, install and export compactor storage systems, and quote dealers and stockists on rate contract.
Specifications — Mobile Compactor
Mobile Compactor are built on our
Mobile Compactor Storage Systems range, so the figures below are that
range's standard sizes.
Spanco manufactures to order, so these are what is
produced at the Bahadurgarh plant rather than a fixed catalogue size.
Final bay loading is confirmed against your pallet weight, bay width and
level configuration before drawings are issued.
Built to the ranges listed below — sizes are made to your bay.
Standard manufacturing ranges for Mobile Compactor Storage Systems
Unit height
2000 mm or 2200 mm
Levels per bay
4 to 6
Load per bay
300 kg to 1000 kg
System length
5000 mm to 12000 mm
Drive
Manual push-pull or chain-driven handle
Configuration
Single-access or double-access (two-way)
Material
Mild steel
Finish
Powder coated
Configuration options
Central locking
Anti-tilt and safety brake
Floor-embedded or surface-mounted rail
Shelf dividers and file separators
Index card holders
Questions buyers ask before ordering
How much floor space do Mobile Compactors save?
Conventional shelving spends most of its area on aisles nobody is standing in. Mobile Compactors put the bays on rails so only the aisle in use is open, which recovers a large share of that floor. Our systems run 300 kg to 1000 kg per bay, 4 to 6 levels, in lengths from 5 m to 12 m.
How much floor space do Mobile Compactor Systems save?
Conventional shelving spends most of its area on aisles nobody is standing in. Mobile Compactor Systems put the bays on rails so only the aisle in use is open, which recovers a large share of that floor. Our systems run 300 kg to 1000 kg per bay, 4 to 6 levels, in lengths from 5 m to 12 m.
How much floor space do Mobile Compactor Storage Racks save?
Conventional shelving spends most of its area on aisles nobody is standing in. Mobile Compactor Storage Racks put the bays on rails so only the aisle in use is open, which recovers a large share of that floor. Our systems run 300 kg to 1000 kg per bay, 4 to 6 levels, in lengths from 5 m to 12 m.
How much floor space do Industrial Mobile Compactor Storage Systems save?
Conventional shelving spends most of its area on aisles nobody is standing in. Industrial Mobile Compactor Storage Systems put the bays on rails so only the aisle in use is open, which recovers a large share of that floor. Our systems run 300 kg to 1000 kg per bay, 4 to 6 levels, in lengths from 5 m to 12 m.
How much space does a mobile compactor actually save?
Conventional shelving spends most of its floor area on aisles standing empty. A compactor puts the bays on rails so they close together and only the aisle you are using is open, which recovers a large share of that floor. The exact gain depends on how many bays you run and how many aisles the fixed shelving needed.
Does the floor have to be cut for the rails?
Not necessarily. Rails can be embedded flush in the slab, which is neater and lets a trolley roll across, or surface-mounted on a sub-frame where cutting the slab is not acceptable. In leased or already-finished buildings, surface mounting is usually the answer.
Is it safe if someone is standing in the aisle?
We fit anti-tilt guides and a brake so a bay cannot be moved while the aisle is occupied. Central locking is available where the contents are confidential, which is common in hospital records, bank and legal archives.
Is it manual or motorised?
Our systems are manual push-pull on lighter loads, or chain-driven through a handle where the loaded mass makes direct pushing impractical. Bay loads run from 300 kg to 1000 kg and systems from 5 m to 12 m in length.
Can compactors be used for things other than files?
Yes. The same mechanism suits spares, tooling, textiles and pharmacy stock. If the goods are palletised, pallet racking is normally the better answer; if the constraint is height rather than aisle width, look at a mezzanine floor instead.
How much space can I save with a Mobile Compactor?
<p>A <strong>Mobile Compactor Storage System</strong> can save up to 50% to 60% of your floor space. By eliminating multiple permanent aisles and using a single movable aisle, you can double your storage capacity in the same square footage. As a <strong>Mobile Compactor Manufacturer in Delhi</strong>, we customize these systems to fit your specific room dimensions.</p>
Is the floor in my Delhi office strong enough for a compactor?
<p>Mobile compactors carry high-density loads, so floor strength is vital. Our technical team at <strong>Spanco Storage Systems</strong> provides on-site structural audits in Delhi to assess your floor's load-bearing capacity before installation. We also offer specialized base frames to distribute weight evenly.</p>
What makes your compactors different from local traders?
<p>Unlike traders, we are a direct <strong>Mobile Compactor Manufacturer in Delhi</strong> with a dedicated <strong>production unit in Bahadurgarh</strong>. We use high-grade CRCA steel, precision-engineered drive gears for effortless movement, and a 7-tank anti-rust powder coating process that ensures 10+ years of durability.</p>
Are these mobile storage units secure for sensitive documents?
<p>Yes. Every <strong>Mobile Compactor in India</strong> supplied by Spanco comes with a centralized locking system. When the units are pushed together and locked, the contents are completely inaccessible, making them perfect for hospitals, banks, and government offices.</p>
Do you provide maintenance for mobile compactors in Delhi-NCR?
<p>As a leading <strong>Mobile Compactor Dealer in Delhi</strong>, we provide annual maintenance services (AMC). This includes track cleaning, gear lubrication, and alignment checks to ensure your system remains silent and smooth for years to come.</p> </div>
We hold no Delhi stock and have no Delhi branch. Everything is made to order at our Bahadurgarh plant, inside the NCR, and installed at your premises by our own team. The plant is open to visit.
Steps of manufacture
How we work
Every rack on this site is made on one line at our own
5000 m² plant in Bahadurgarh.
Nothing is bought in and re-badged, which is why we can answer for the
steel grade, the coating and the bay loading on the same call.
1
Steel coil in
Cold-rolled and hot-rolled coil from TATA Steel and SAIL arrives at the Bahadurgarh plant and is checked against IS 513 and IS 10743 before anything is cut.
2
Punching
Coil is slit to width and punched on the press. Upright perforation pitch is set here, and it is what decides the beam levels you can later move.
3
Roll forming
Flat strip is passed through the forming line and comes out as the finished section — upright, beam or panel — with the stiffening bends that carry the load.
4
Shot blasting
Mill scale and rust are stripped off the formed sections so that paint has clean, keyed steel to hold on to. Skipping this is why cheap racking flakes.
5
Welding and assembly
Bracing is welded to the uprights and beam end-connectors are fitted. Frames are squared on the jig so bays line up on site rather than being forced true.
6
Powder coating
Sections are pre-treated and powder coated, then oven cured. The coat is what stands up to forklift rub, humidity and cold-store condensation.
7
Packing
Uprights, beams and accessories are bundled by bay and labelled, so the right parts reach the right run and nothing is counted twice on site.
8
Delivery and installation
Dispatch runs approximately 2 weeks from order confirmation. Our own team installs and hands over; everything is bolted, so a run can be re-pitched or relocated later.
